VENEZIA V6 24V
-
Code:78250036
-
Weight:4.820 Kgs
Unleash the power of pristine audio on the water with the VENEZIA V6 24V Marine Amplifier. This robust 6-channel amplifier delivers an impressive 6x270W of pure, unadulterated sound, ensuring your marine audio system cuts through the noise of the waves and provides an unparalleled listening experience.
Engineered for the demanding marine environment, the VENEZIA V6 boasts exceptional durability and reliability. Its 24V design is perfect for larger boats and yachts, providing the necessary power to drive even the most demanding speaker setups. Whether you're cruising, fishing, or enjoying watersports, this amplifier will transform your boat into a floating concert hall.
Experience crystal-clear highs, rich mids, and deep, resonating bass. The VENEZIA V6 is meticulously crafted to reproduce every note with stunning accuracy, ensuring you hear your music exactly as the artist intended. Its advanced circuitry minimizes distortion and maximizes efficiency, delivering exceptional performance without draining your battery.
Upgrade your marine audio system today with the VENEZIA V6 24V Marine Amplifier and experience the difference that true power and clarity can make.
- 6 Channels for versatile speaker configurations
- 6x270W Output for powerful and immersive sound
- 24V Design ideal for larger boats and yachts
- Marine-Grade Construction for durability in harsh environments
- Exceptional Clarity and minimal distortion
Estimated Shipping
to Veliko Tarnovo starts at
€2.32
outside Veliko Tarnovo starts at
€2.38
Quick Buy
VENEZIA V6 24V - Marine 6 Channel Amplifier
Experience unparalleled audio performance on the water with the VENEZIA V6 24V Marine Amplifier. Engineered for marine environments, this powerful 6-channel amplifier delivers crystal-clear sound and robust power to elevate your onboard entertainment system. With a total power output of 1740W, the VENEZIA V6 ensures every note is heard with exceptional clarity and depth, even in noisy marine conditions.
Key Features and Benefits
- High Power Output: Delivers up to 290W x 6 channels at 2Ω, ensuring powerful and clear audio.
- Versatile Configuration: Configurable as 6, 5, 4, or 3 channels, providing flexibility for various speaker setups.
- Adjustable Crossovers: Precise sound tuning with adjustable high-pass and band-pass filters for optimal audio clarity.
- Marine-Grade Durability: Built to withstand harsh marine environments, ensuring long-lasting performance.
- Multiple Inputs: Features A, B, and C channel pre-inputs for versatile connectivity options.
Detailed Specifications
The VENEZIA V6 24V is packed with features designed to enhance your audio experience:
General Specifications
- Channels: 6 - 5 - 4 - 3
- Power Supply Voltage: 22 ÷ 33 VDC
- Idling Current: 1 A (Power ON) / 0.04 mA (Power OFF)
- Max Consumption: 30 A @ 1Ω, 28.8 VDC
Amplifier Stage
- THD: <0.06% (100Hz @ 4Ω)
- Bandwidth: 10 ÷ 42 kHz
- S/N Ratio: 100 dB (A weighted @ 1 V)
- Damping Factor: 130 (100Hz @ 4Ω)
- Pre-In Sensitivity: 0.2 ÷ 5 VRMS
- Pre-In Impedance: 10 kΩ
Output Power (RMS) @ 28.8 VDC, THD 1%
- 6Ch: 160 W x 6 (4Ω) / 290 W x 6 (2Ω)
- 5Ch: 160 x 4 (4Ω) + 580 x 1 (4Ω) / 290 x 4 (2Ω) + 580 x 1 (4Ω)
- 4Ch: 160 x 2 (4Ω) + 580 x 2 (4Ω) / 290 x 2 (2Ω) + 580 x 2 (4Ω)
- 3Ch: 580 x 3 (4Ω)
- Total Power: 1740 W
Inputs and Filters
- Inputs: A Ch. Pre in, B Ch. Pre in, C Ch. Pre in
- Pre Out: No
- Ch. A Filters: MONO IN (on/off), By-pass, Hi-pass (50 ÷ 500 Hz / 500 Hz ÷ 5 kHz @ 12 dB/Oct)
- Ch. B Filters: MONO IN (on/off), By-pass, Hi-pass (50 ÷ 500 Hz @ 12 dB/Oct), Band-pass (50 ÷ 500 Hz / 500 Hz ÷ 5 kHz @ 12 dB/Oct)
- Ch. C Filters: MONO IN (on-off), By-pass, Hi-pass (50 ÷ 500 Hz @ 12 dB/Oct), Lo-pass (50 ÷ 500 Hz @ 12 dB/Oct), Bass boost 50 Hz (adjust): (0 ÷ 12) dB
Physical Specifications
- Dimensions:
- A: 330 mm / 13 in
- B: 300 mm / 11.18 in
- C: 200 mm / 7.87 in
- D: 170 mm / 6.7 in
- E: 54 mm / 2.12 in
- Weight: 3.72 kg / 8.2 lb
Upgrade your marine audio system with the VENEZIA V6 24V and enjoy powerful, clear, and reliable sound on every voyage. Its robust design and versatile features make it the perfect choice for any boat.
