Honda BF10DK2 SHU – 10 HP, 6 A Charging System
-
Code:BF10DK2SHU
-
Weight:42.000 Kgs
Honda BF10DK2 SHU – 10 HP, Short Shaft, Tiller Control, 6 A Charging System
The Honda BF10DK2 SHU is a compact and reliable 4-stroke outboard motor delivering 10 HP, designed for small to medium-sized boats. Its 222 cc twin-cylinder engine provides smooth operation, low vibration and easy handling.
This version features a short shaft (S), tiller steering and manual recoil start, making it a practical choice for inflatable, aluminium, fishing and small motor boats with a compatible transom height. The integrated 6 A charging system can support battery charging and compatible onboard electrical equipment.
Standard equipment includes an aluminium 4-blade propeller and external fuel tank, together with the required fuel-system components. Compact dimensions and manual engine tilt make the BF10DK2 SHU well suited to fishing, recreational cruising and everyday use on inland and coastal waters.
Suitable for: small to medium-sized boats with a transom height and maximum rated engine power compatible with a 10 HP short-shaft outboard.
Estimated Shipping
to Veliko Tarnovo starts at
€12.80
outside Veliko Tarnovo starts at
€17.28
Quick Buy
Honda BF10DK2 SHU – 10 HP Short-Shaft Outboard Motor
The Honda BF10DK2 SHU is a 4-stroke petrol outboard motor delivering 10 HP (7.4 kW). It is designed for boat owners looking for compact dimensions, reliable performance and simple, direct tiller control.
Its 222 cc, 2-cylinder OHC engine features water cooling with thermostat and Honda PGM-IG electronic ignition. The full-throttle operating range is 5,000–6,000 rpm. Fuel is supplied through a carburettor, while exhaust gases are discharged through the propeller hub.
Tiller Control & Short Shaft
The SHU version features tiller steering and manual recoil starting. Its short-shaft configuration is intended for boats with a compatible low transom, with a recommended mounting height of approximately 433–434 mm.
Tiller steering provides direct control of throttle and direction, making this configuration particularly suitable for compact boats where a separate remote steering console is not required.
Charging System & Equipment
The engine is equipped with a 6 A charging system, allowing it to support onboard battery charging and compatible electrical equipment.
Standard equipment includes an aluminium 4-blade propeller and external fuel tank. The BF10 also features manual tilt adjustment, F–N–R (Forward–Neutral–Reverse) gears, an emergency stop switch and warning systems for oil pressure and engine overheating.
Key Specifications
- Model: Honda BF10DK2 SHU
- Power: 10 HP / 7.4 kW
- Engine: 4-stroke OHC, 2-cylinder
- Displacement: 222 cc
- Full-throttle range: 5,000–6,000 rpm
- Cooling: water-cooled with thermostat
- Fuel system: carburettor
- Ignition: electronic PGM-IG
- Starting: manual recoil
- Steering: tiller handle
- Shaft: short (S)
- Recommended transom height: approx. 433–434 mm
- Gears: F–N–R
- Charging system: 6 A
- Trim / tilt: manual
- Propeller: 4-blade aluminium
- Fuel tank: external, approx. 12 L
- Dry weight: approx. 42 kg
What Boats Is It Suitable For?
The Honda BF10DK2 SHU is a practical choice for inflatable boats, aluminium boats, fishing boats and small motor boats designed for approximately 10 HP and a short-shaft outboard.
Before installation, always check the boat manufacturer's specifications for transom height, maximum permitted engine power and maximum engine weight to ensure the correct engine-to-boat combination.
Who it’s for
For owners of boats compatible with a 10 HP short-shaft outboard who need tiller steering and manual recoil starting. Selection must follow the boat rating plate and installation requirements.
FAQ
How is the Honda BF10DK2 SHU started?
This version has manual recoil starting and tiller steering. Its 6 A charging system does not mean that an electric starter is fitted.
Which transom is the SHU version intended for?
This is the short-shaft (S) version. Before ordering, check the transom dimensions and installation requirements of your specific boat; engine power alone is not sufficient for selection.
Is it suitable for my inflatable or aluminium boat?
Check the boat documentation for maximum permitted engine power and weight, as well as transom height. Hull material alone does not establish compatibility.
What is the difference between SHU and LHU?
SHU has a short shaft; LHU has a long shaft. Do not substitute one for the other without checking the installation. This card is for SKU BF10DK2SHU.
What should I confirm before ordering?
Provide your boat model and transom height. Confirm the delivery contents, required accessories and preparation for first use for this exact SKU.
